Product: Cleaved-IL-1 beta (Asp116) Antibody
Catalog: AF4006
Description: Rabbit polyclonal antibody to Cleaved-IL-1 beta (Asp116)
Application: WB IHC IF/ICC
Reactivity: Human, Mouse, Rat, Zebrafish
Mol.Wt.: 17 kDa; 31kD(Calculated).
Uniprot: P01584
RRID: AB_2801567

View similar products>>

   Size Price Inventory
 50ul $250 In stock
 100ul $350 In stock
 200ul $450 In stock

Lead Time: Same day delivery

For pricing and ordering contact:
Local distributors

Product Info

WB 1:500-1:2000, IHC 1:50-1:200, IF/ICC 1:100-1:500
*The optimal dilutions should be determined by the end user.

WB: For western blot detection of denatured protein samples. IHC: For immunohistochemical detection of paraffin sections (IHC-p) or frozen sections (IHC-f) of tissue samples. IF/ICC: For immunofluorescence detection of cell samples. ELISA(peptide): For ELISA detection of antigenic peptide.

Cleaved-IL-1 beta (Asp116) Antibody detects endogenous levels of fragment of activated IL-1 beta resulting from cleavage adjacent to Asp116.
Cite Format: Affinity Biosciences Cat# AF4006, RRID:AB_2801567.
The antiserum was purified by peptide affinity chromatography using SulfoLink™ Coupling Resin (Thermo Fisher Scientific).
Rabbit IgG in phosphate buffered saline , pH 7.4, 150mM NaCl, 0.02% sodium azide and 50% glycerol. Store at -20 °C. Stable for 12 months from date of receipt.


Catabolin; H1; IL 1; IL 1 beta; IL-1 beta; IL1 BETA; IL1B; IL1B_HUMAN; IL1F2; Interleukin 1 beta; Interleukin-1 beta; OAF; OTTHUMP00000162031; Preinterleukin 1 beta; Pro interleukin 1 beta;


P01584 IL1B_HUMAN:

Expressed in activated monocytes/macrophages (at protein level).


PTMs - P01584 As Substrate

Site PTM Type Enzyme
Y140 Phosphorylation
S200 Phosphorylation
S269 Phosphorylation

Research Backgrounds


Potent proinflammatory cytokine. Initially discovered as the major endogenous pyrogen, induces prostaglandin synthesis, neutrophil influx and activation, T-cell activation and cytokine production, B-cell activation and antibody production, and fibroblast proliferation and collagen production. Promotes Th17 differentiation of T-cells. Synergizes with IL12/interleukin-12 to induce IFNG synthesis from T-helper 1 (Th1) cells.


Activation of the IL1B precursor involves a CASP1-catalyzed proteolytic cleavage. Processing and secretion are temporarily associated.

Subcellular Location:

Cytoplasm>Cytosol. Lysosome. Secreted>Extracellular exosome. Secreted.
Note: The precursor is cytosolic. In response to inflammasome-activating signals, such as ATP for NLRP3 inflammasome or bacterial flagellin for NLRC4 inflammasome, cleaved and secreted. IL1B lacks any known signal sequence and the pathway(s) of its secretion is(are) not yet fully understood (PubMed:24201029). On the basis of experimental results, several unconventional secretion mechanisms have been proposed. 1. Secretion via secretory lysosomes: a fraction of CASP1 and IL1B precursor may be incorporated, by a yet undefined mechanism, into secretory lysosomes that undergo Ca(2+)-dependent exocytosis with release of mature IL1B (PubMed:15192144). 2. Secretory autophagy: IL1B-containing autophagosomes may fuse with endosomes or multivesicular bodies (MVBs) and then merge with the plasma membrane releasing soluble IL1B or IL1B-containing exosomes (PubMed:24201029). However, autophagy impacts IL1B production at several levels and its role in secretion is still controversial. 3. Secretion via exosomes: ATP-activation of P2RX7 leads to the formation of MVBs containing exosomes with entrapped IL1B, CASP1 and other inflammasome components. These MVBs undergo exocytosis with the release of exosomes. The release of soluble IL1B occurs after the lysis of exosome membranes (By similarity). 4. Secretion by microvesicle shedding: activation of the ATP receptor P2RX7 may induce an immediate shedding of membrane-derived microvesicles containing IL1B and possibly inflammasome components. The cytokine is then released in the extracellular compartment after microvesicle lysis (PubMed:11728343). 5. Release by translocation through permeabilized plasma membrane. This may occur in cells undergoing pyroptosis due to sustained activation of the inflammasome (By similarity). These mechanisms may not be not mutually exclusive.

Extracellular region or secreted Cytosol Plasma membrane Cytoskeleton Lysosome Endosome Peroxisome ER Golgi apparatus Nucleus Mitochondrion Manual annotation Automatic computational assertionSubcellular location
Tissue Specificity:

Expressed in activated monocytes/macrophages (at protein level).

Subunit Structure:

Monomer. In its precursor form, weakly interacts with full-length MEFV; the mature cytokine does not interact at all. Interacts with integrins ITGAV:ITGBV and ITGA5:ITGB1; integrin-binding is required for IL1B signaling.


Belongs to the IL-1 family.

Research Fields

· Cellular Processes > Cell growth and death > Necroptosis.   (View pathway)

· Environmental Information Processing > Signal transduction > MAPK signaling pathway.   (View pathway)

· Environmental Information Processing > Signaling molecules and interaction > Cytokine-cytokine receptor interaction.   (View pathway)

· Environmental Information Processing > Signal transduction > NF-kappa B signaling pathway.   (View pathway)

· Environmental Information Processing > Signal transduction > TNF signaling pathway.   (View pathway)

· Human Diseases > Drug resistance: Antineoplastic > Antifolate resistance.

· Human Diseases > Endocrine and metabolic diseases > Non-alcoholic fatty liver disease (NAFLD).

· Human Diseases > Endocrine and metabolic diseases > Type I diabetes mellitus.

· Human Diseases > Neurodegenerative diseases > Alzheimer's disease.

· Human Diseases > Neurodegenerative diseases > Prion diseases.

· Human Diseases > Infectious diseases: Bacterial > Salmonella infection.

· Human Diseases > Infectious diseases: Bacterial > Pertussis.

· Human Diseases > Infectious diseases: Bacterial > Legionellosis.

· Human Diseases > Infectious diseases: Parasitic > Leishmaniasis.

· Human Diseases > Infectious diseases: Parasitic > Chagas disease (American trypanosomiasis).

· Human Diseases > Infectious diseases: Parasitic > African trypanosomiasis.

· Human Diseases > Infectious diseases: Parasitic > Malaria.

· Human Diseases > Infectious diseases: Parasitic > Amoebiasis.

· Human Diseases > Infectious diseases: Bacterial > Tuberculosis.

· Human Diseases > Infectious diseases: Viral > Measles.

· Human Diseases > Infectious diseases: Viral > Influenza A.

· Human Diseases > Infectious diseases: Viral > Herpes simplex infection.

· Human Diseases > Immune diseases > Inflammatory bowel disease (IBD).

· Human Diseases > Immune diseases > Rheumatoid arthritis.

· Human Diseases > Immune diseases > Graft-versus-host disease.

· Organismal Systems > Development > Osteoclast differentiation.   (View pathway)

· Organismal Systems > Immune system > Toll-like receptor signaling pathway.   (View pathway)

· Organismal Systems > Immune system > NOD-like receptor signaling pathway.   (View pathway)

· Organismal Systems > Immune system > Cytosolic DNA-sensing pathway.   (View pathway)

· Organismal Systems > Immune system > Hematopoietic cell lineage.   (View pathway)

· Organismal Systems > Immune system > IL-17 signaling pathway.   (View pathway)

· Organismal Systems > Immune system > Th17 cell differentiation.   (View pathway)

· Organismal Systems > Sensory system > Inflammatory mediator regulation of TRP channels.   (View pathway)


1). Hypoxic acclimation improves cardiac redox homeostasis and protects heart against ischemia-reperfusion injury through upregulation of O-GlcNAcylation. Redox Biology, 2021 (PubMed: 33964586) [IF=11.4]

Application: WB    Species: rat    Sample: heart

Fig. 3. | HA-induced inflammation stimulated protein O-GlcNAcylation in hearts. A, Immunoblot analysis of IL-1β and IL-6 in the Control and HA hearts (n = 9 per group).

2). Water-extracted Lonicera japonica polysaccharide attenuates allergic rhinitis by regulating NLRP3-IL-17 signaling axis. Carbohydrate Polymers, 2022 (PubMed: 36184153) [IF=11.2]

3). DKK3 ameliorates neuropathic pain via inhibiting ASK-1/JNK/p-38-mediated microglia polarization and neuroinflammation. Journal of Neuroinflammation, 2022 (PubMed: 35658977) [IF=9.3]

4). Mesenchymal stem cells protect against TBI-induced pyroptosis in vivo and in vitro through TSG-6. Cell Communication and Signaling, 2022 (PubMed: 35982465) [IF=8.4]

5). Shen Shuai Ⅱ Recipe attenuates renal fibrosis in chronic kidney disease by improving hypoxia-induced the imbalance of mitochondrial dynamics via PGC-1α activation. PHYTOMEDICINE, 2022 (PubMed: 35104767) [IF=7.9]

6). nNovel insights into antidepressant mechanism of Kai Xin San formula: inhibiting NLRP3 inflammasome activation by promoting autophagy. PHYTOMEDICINE, 2021 (PubMed: 34735906) [IF=7.9]

7). Formononetin protects against inflammation associated with cerebral ischemia-reperfusion injury in rats by targeting the JAK2/STAT3 signaling pathway. BIOMEDICINE & PHARMACOTHERAPY, 2022 (PubMed: 35339827) [IF=7.5]

8). Artesunate inhibits macrophage-like phenotype switching of vascular smooth muscle cells and attenuates vascular inflammatory injury in atherosclerosis via NLRP3. Biomedicine & pharmacotherapy = Biomedecine & pharmacotherapie, 2024 (PubMed: 38325261) [IF=7.5]

Application: WB    Species: Human    Sample: HVSMCs

Fig. 4. The anti-inflammatory effects of artesunate. (A) Immunofluorescence for NLRP3 and IL-1β expression in vitro. (B) Relative protein expression of NLRP3, Cleaved-CASP1, and Cleaved-IL-1β in vitro. *P 

9). Protective effects of Eleutheroside E against high-altitude pulmonary edema by inhibiting NLRP3 inflammasome-mediated pyroptosis. Biomedicine & pharmacotherapy = Biomedecine & pharmacotherapie, 2023 (PubMed: 37776644) [IF=7.5]

Application: WB    Species: Rat    Sample: lung tissues

Fig. 6. Effects of EE on the expression of pyroptosis-related proteins in the lung tissues of rats with hypobaric hypoxia. (A) Pyroptosis-related proteins expressions in the lung tissue were analyzed with western blot. (B) Bar graphs show semi-quantitative results of pyroptosis-related protein expressions. Values (n = 7 per group) are represented as means ± SEM.

10). Astragaloside IV alleviates PM2.5-caused lung toxicity by inhibiting inflammasome‐mediated pyroptosis via NLRP3/caspase-1 axis inhibition in mice. BIOMEDICINE & PHARMACOTHERAPY, 2022 (PubMed: 35462332) [IF=7.5]
